General Data-LLDPE for Rotation
Property NG 558 LLDPE Natural Granule BG 558 LLDPE Black Granule BP 558 LLDPE Black Powder NP 558 LLDPE Natural Powder
Density (m/ cm³) ASTM D-1505 0.933 0.937 0.937 0.933
Melt Index (g/ 10 min) ASTM D-1238 6.0 5.36 5.36 6.0
Tensile Yieild Strenght (kg/cm²) ASTM D-638 200 190 210 200
Elongation at Break (%) ASTM D-638 1050 920 910 1050
Hardness (shore) ASTM D-2240 D56 D56 D56 D56
Stiffness (kg/cm²) ASTM D-747 5500 5500 5500 5500
Brittleness Temp (°C) ASTM D-746 <-76 <-76 <-76 <-76
Vicat Softeness point ASTM D-1525 112°c 112°c 112°c 112°c
Carbon Content 1% 1%
Weather Ability Confirmed Confirmed Confirmed Confirmed
ESCR >1000 >1000 >1000 >1000
Melting Point 126 126 126 126
IZOD Impact (Noticed) 55 55


Powder Distribution
Size
Micron
   Mesh
Specifications Typical Distribution
Over 600
   Larger then 30
Max 1% 0.3 - 0.8%
500 - 600
   30 - 32
Max 10% 5% - 8%
212 - 500
   32 - 70
Min 70% 75% - 80%
150 - 212
   70 - 100
Max 15% 8% - 14%
0 - 150
   Smaller then 100
Max 10% 5% - 9%
